E4HD Mine Duty Primary Belt Cleaner

e4hd-cleaner

Ev-R-Wear Blade

Our special formulated urethane with additives has been tested and proven to last longer than any other blade on the market.

  • Premium urethane
  • Additive for lubricity (non-stick)
  • Additive for high abrasion

With over 35 years molding experience.

Eagle Torsion System

This revolutionary design is the simplest and most accurate tensioning system on the market. Only 4 components make up the Eagle Torsion System.

  • Universal torsion mounting bracket
  • Stainless steel spring
  • Eagle Torsion ring
  • Tension guide ring

Features and Benefits

Universal Mounting Bracket

  • Can be flange mounted or foot mounted
  • Elongated holes allow for easy alignment of installation
  • Composite molded bushing eliminates corrosion and build-up between bracket and mounting tube. Allow constant blade pressure to belt
  • Set screw that allows pre-tensioning of cleaner making it more accurate

Designed with your maintenance personnel’s safety and time in mind!


Specifications and Guidelines

Belt Width Belt Width -2″ (50mm) Belt Width -8″ (200mm)
in mm in mm Part No. in mm Part No.
18 450 16 400 E4M18 10 250 E4M12
24 600 22 550 E4M24 16 400 E4M18
30 750 28 700 E4M30 22 550 E4M24
36 900 34 850 E4M36 28 700 E4M30
42 1050 40 1000 E4M42 34 850 E4M36
48 1200 46 1150 E4M48 40 1000 E4M42
54 1350 52 1300 E4M54 46 1150 E4M48
60 1500 58 1450 E4M60 52 1300 E4M54
72 1800 70 1750 E4M72 64 1600 E4M66
84 2100 82 2050 E4M84 76 1900 E4M78
96 2400 94 2380 E4M96 88 2200 E4M90

Belt Cleaning Brochure

Product Resources

Brochure
Ordering Info
Replacement Blade
Blade DataSheet
